Semi-automatic paver for athletic tracks and multipurpose sports surfaces. Working width up to 2,700 mm (8,5 foot); area performance max. 730m²/h

The PlanoMatic P227 for athletic tracks is the easiest of all SMG pavers considering handling. On the basis of the proven, however fully automatic model P703, the P227 convinces due to a working width of 2.700 mm and the intentional reduction to the most important features.

P227 is equipped with only one control panel which can be fixed either on the left or ride side of the machine enabling to access the most important functions easily and clearly.

The variable adjustable installation speed is max. 4.5 m/min, thus providing a theoretical performance of approx. 730 m²/h. The machine is easy to manoeuvre with a weight of 830 kg and equipped with driving chains of 80 mm width.

For the optimal surface quality the compaction can be adjusted accordingly by changing the angle of the screed. The oscillating speed of the screed is adjustable and therefore provides the optimum surface quality. Material limiters installed on the side of the screed assure exact paving edges for surfaces without joints. The P227 can be lifted with the help of the hand pump.
